NOVANTA-CINQUECENTO [KW 480 ÷ 8000]

NOVANTA-CINQUECENTO [kW 480 ÷ 8000]

R91A R92A R93A R512A R515A R520A R525A

Monoblock burners made in die-cast aluminum housing with a relative flange to work on heating generators.

These burners include the NOVANTA series up to 4100 kW and CINQUECENTO series up to 8000 kW.

These burners, available with the Progressive or Modulating operation, are provided with a combustion head “bell-shaped” for high performance and low emissions.

The electrical servomotor acts both on the butterfly valve and on the air damper; it works through a variable profile cam in order to achieve the best results of combustion.

The control panel facia is printed with a mimic diagram complete with lamps to show the sequential stages of the burner operation.

Despite to its considerable dimension, these series permit all standard maintenance operations to be carried out by one single person.

Description

Type	Model	Power kW		Electric power	Fan motor 2800 g/1′ kW	Gas connections
		min.	max.
R91A	M-.xx.S.IT.A.1.xxx	480	2670	230V 3 ac / 400V 3N ac	4	2″ – DN65 – 80 – 100	PR-MD
R92A	M-.xx.S.IT.A.1.xxx	480	3050	230V 3 ac / 400V 3N ac	6	2″ – DN65 – 80 – 100	PR-MD
R93A	M-.xx.S.IT.A.1.xxx	550	4100	230V 3 ac / 400V 3N ac	8	2″ – DN65 – 80 – 100	PR-MD
R512A	M-.xx.S.IT.A.1.xxx	600	4500	230V 3 ac / 400V 3N ac	9,2	2″ – DN65 – 80 – 100	PR-MD
R515A	M-.xx.S.IT.A.1.xxx	770	5200	230V 3 ac / 400V 3N ac	11	2″ – DN65 – 80 – 100	PR-MD
R520A	M-.xx.S.IT.A.1.xxx	1000	6400	230V 3 ac / 400V 3N ac	15	2″ – DN65 – 80 – 100	PR-MD
R525A	M-.xx.S.IT.A.1.xxx	2000	8000	400V 3N ac	18,5	DN65 – 80 – 100	PR-MD
