The new standard G type NOVANTA series Low NOx burners Class 2 (< 120 mg/kWh), made in aluminum housing with a backward curved centrifugal impeller is studied and developed to get high performance and efficiency combined with low emissions. This series with a maximum power of 4000 kW, is in this selection of product that is particularly competitive. The user-friendly application and maintenance are the strengths of these burners.
Technical data
Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
G335A | M-.XX.SR.IN.A.1.XXX | 280 kW | 3,350 kW | 230 V 1N AC 50 Hz | 5.5 kW |
