The new H type CINQUECENTO series Low NOx burners Class 3 (< 80 mg/kWh) made in aluminium housing with a backward curved centrifugal impeller has been developed to meet the current and future requests regarding the low emissions of NOx . The innovation of the combustion head allows to achieve substantial improvements in terms of emissions reduction, flame stability and reliability. The perfect mix of air/gas within the combustion head of these burners, guarantees a very uniform flame in all working conditions.
Technical data
Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
H365X | M-.XX.XR.IN.A.1.XXX | 650 kW | 3,650 kW | 230 V 1N AC 50 Hz | 7.5 kW |
