This range of medium output burners Low NOx Class 2 (< 120 mg/kWh), made in aluminum, was studied and developed to get high performance and efficiency combined with low emissions.
The CINQUECENTO series with a maximum power of 8000 kW, is in this selection of product that is particularly competitive. The user-friendly application and maintenance are the strengths of these burners.
Technical data
Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
R515A | M-.XX.S.IN.A.1.XXX | 770 kW | 5,200 kW | 230 V 1N AC 50 Hz | 11.0 kW |
