The series NOVANTA Low NOx Class 3 (< 80 mg/kWh) has been developed to meet the current and future requests regarding the low emissions of NOx. The innovation of the combustion head allows to achieve substantial improvements in terms of emissions reduction, flame stability and reliability. The perfect mix of air/gas within the combustion head of these burners, guarantees a very uniform flame in all working conditions.
Technical Data
Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
RX92R | M-.XX.X.IN.A.1.XX | 350 kW | 2,550 kW | 230V 1N AC 50 Hz | 7.5 kW |
